| Model No.: | RTD | Protect Wavelength: | 630-660nm & 800-830nm |
|---|
| Transmittance: | 30% | Application: | Red Laser, 808nm Diodes |
|---|
| Material: | Polycarbonate | Suit for: | 635nm, 660nm, 808nm etc., |
|---|
| L-Rating: | 660-660nm DIR LB3&800-830nm DIR LB5 | OD Value: | OD3+@630-660nm & OD5+@800-830nm |
|---|
Advantage:
1. Good visibility.
2. Comfort to wear.
3. Safety glasses with wrap-around design.
4. Flank with unique ventilation and protection system, protect
eyes from splashing.
| Normal Type | Typical For | Transmittance | O.D | L-Rating |
| GTY | 532&1064nm | 30% | 200 - 540nm O.D 6+ & 900 - 1100nm O.D 5+ | 315 - 540nm DIRM LB5 & 900 - 1070nm DIR LB5 |
| RTD-3 | 635&808nm&980nm | 35% | 630 - 660nm O.D2+ & 800nm - 1100nm O.D5+ | 630 - 660nm DIR LB2 & 800 - 1100nm DIR LB5 |
| RTD-4 | 635&905nm&980nm | 37% | 630 - 660nm O.D3+ & 800nm - 830nm O.D3+ & 900 - 1100nm O.D5+ | 630 - 660nm DIR LB3 & 800 - 830nm DIR LB3 & 900 - 1100nm DIR LB5 |
| ADY | 755&808&1064nm | 40% | 740 - 1100nm O.D 5+ & 780 - 1070nm O.D7+ | 740 - 1100nm DIR LB5 & 800 - 1070nm IR LB7 |
| DTY | 980&1064&1320nm | 40% | 800 - 1700nm O.D 4+ & 900 - 1100nm O.D 5+ | 800 - 1400nm DIR LB4 & 1400 - 1700nm DI LB3 |
| YHP | High Power 808&980&1064nm | 60% | 800 - 1100nm O.D 5+ & 1060 - 1070nm O.D 7+ | 800 - 1100nm DIR LB5 & 1000 - 1070nm IR LB7 |
| CHP | 10600nm | 90% | 9000-11000nm O.D 6+ | 9000-11000nm DI LB3 |
|
|
|
| IPL | 200 – 1400nm | 10% | IPL Machine | |
|
|
|
| YLW | 1064nm Laser Window | 40% | 800 -1100nm O.D 4+ & 1064nm O.D 6+ | 1064nm DIR LB5 |
Payment and Shipment Information:
1. Payment Information
1. T/T (Wire Transfer).
2. WESTERN UNION.
3. PAYPAL.
2. Shipping
1. We will ship the items within 3 working days after the payment
confirmed.
2. We can ship to you by UPS/DHL/TNT/EMS/FedEx. Please contact us
directly and we will use your preferred ways. For the Countries &
Regions where EMS cannot deliver, please choose other shipping
ways.
3. We are not responsible for any accidents, delays or other issues
caused by the forwarder.
4. Any import fees or charges are on the buyer's account.
