| Model No.: | RTD-4 | Protect Wavelength: | 630-660nm & 800-830nm & 900-1100nm |
|---|
| Transmittance: | 37% | OD Value: | OD3+@630-660nm & OD3+@800-830nm & OD5+@900-1100nm |
|---|
| Material: | Polycarbonate | Suit for: | 635nm, 660nm, 808nm, 905nm, 980nm etc., |
|---|
Logo: | Customize Logo | Application: | 635nm, 905nm, 980nm Diodes |
|---|
Advantage of laser safety glasses :
Special for ergonomics, harmlessness, comforts, airing and
flexibility.Safety glasses with wrap-around design.Flank with
unique ventilation and protection system, protect eyes from
splashing all-round.
1. Protect Wavelength: 630-660nm&800-830nm&900-1100nm
2. Optical density: 630 - 660nm OD 3+, 800 - 830nm OD 3+, 900 -
1100nm OD5+
3. Visible light transmittance: 37%
4. Available for: 635nm, 905nm, 980nm
5. According : CE EN207
6. Application: red lasers, 905&980nm diodes
Four Frames: 33/36/52/55
Packing details:
1. OEM/ODM service is available to us.
2. Professional gift box
Related Products:
Our factory laser safety glasses strictly according to ANSI Z136
and EN207.
IPL safety glasses and patient eyewear strictly according to EN169.
| Normal Type | Typical For | Transmittance | O.D | L-Rating |
| GTY | 532&1064nm | 30% | 200 - 540nm O.D 6+ & 900 - 1100nm O.D 5+ | 315 - 540nm DIRM LB5 & 900 - 1070nm DIR LB5 |
| RTD-3 | 635&808nm&980nm | 35% | 630 - 660nm O.D2+ & 800nm - 1100nm O.D5+ | 630 - 660nm DIR LB2 & 800 - 1100nm DIR LB5 |
| RTD-4 | 635&905nm&980nm | 37% | 630 - 660nm O.D3+ & 800nm - 830nm O.D3+ & 900 - 1100nm O.D5+ | 630 - 660nm DIR LB3 & 800 - 830nm DIR LB3 & 900 - 1100nm DIR LB5 |
| ADY | 755&808&1064nm | 40% | 740 - 1100nm O.D 5+ & 780 - 1070nm O.D7+ | 740 - 1100nm DIR LB5 & 800 - 1070nm IR LB7 |
| DTY | 980&1064&1320nm | 40% | 800 - 1700nm O.D 4+ & 900 - 1100nm O.D 5+ | 800 - 1400nm DIR LB4 & 1400 - 1700nm DI LB3 |
| YHP | High Power 808&980&1064nm | 60% | 800 - 1100nm O.D 5+ & 1060 - 1070nm O.D 7+ | 800 - 1100nm DIR LB5 & 1000 - 1070nm IR LB7 |
| CHP | 10600nm | 90% | 9000-11000nm O.D 6+ | 9000-11000nm DI LB3 |
|
|
|
| IPL | 200 – 1400nm | 10% | IPL Machine | |
|
|
|
| YLW | 1064nm Laser Window | 40% | 800 -1100nm O.D 4+ & 1064nm O.D 6+ | 1064nm DIR LB5 |
