| Model No.: | CHP |
|---|
| Transmittance: | 90% |
|---|
| OD Value: | OD6+@9000-11000nm |
|---|
| Logo: | Customize Logo |
|---|
| Trademark: | Laserpair |
|---|
| Protect Wavelength: | 9000-11000nm |
|---|
| Suit for: | 10600nm Etc., |
|---|
| Material: | Polycarbonate |
|---|
| Application: | CO2 Laser |
|---|
| HS Code: | 9004909000 |
|---|
Advantage:
1. Stable, clear and flexible PVC curved body, fits the face.
2. 4 vent valves indirect ventilation design prevents lenses from
fogging.
3. Protects you from particles, dust, or spray.
4. The lenses are clear allowing a maximum visible light
transmission.
5. Safety glasses with wrap-around design.
6. Flank with unique ventilation and protection system, protect
eyes from splashing all-round.
LaserPair recommends that you wear laser safety glasses when the
laser class is greater than Class 1. Choose different laser safety glasses according to different laser
wavelengths and working environments.
About this goggles:
1. Optical Density: 9000 - 11000nm OD 6+
2. LB-Rating: 10600nm DI LB3
3. Transmittance: 90%
4. Available for: 10600nm
5. Application: CO2 laser
6. According: CE EN207
Four Kinds of Frames Options ( #33/#36/#52/#55)
User Manual:
Please check the product manual for the specific use of the
product.
CHP-
LASERPAIR- User Manual.pdf
Packing Details:
Each pair of safety glasses comes with a strong hard protective
storage case and a cleaning cloth.
Related Products:
Our factory laser safety glasses are strictly in accordance with ANSI Z136 and EN207.
IPL safety glasses and patient eyewear strictly according to EN169.
| Normal Type | Typical For | Transmittance | O.D | L-Rating |
| GTY | 532&1064nm | 30% | 200 - 540nm O.D 6+ & 900 - 1100nm O.D 5+ | 315 - 540nm DIRM LB5 & 900 - 1070nm DIR LB5 |
| RTD-3 | 635&808nm&980nm | 35% | 630 - 660nm O.D2+ & 800nm - 1100nm O.D5+ | 630 - 660nm DIR LB2 & 800 - 1100nm DIR LB5 |
| RTD-4 | 635&905nm&980nm | 37% | 630 - 660nm O.D3+ & 800nm - 830nm O.D3+ & 900 - 1100nm O.D5+ | 630 - 660nm DIR LB3 & 800 - 830nm DIR LB3 & 900 - 1100nm DIR LB5 |
| ADY | 755&808&1064nm | 40% | 740 - 1100nm O.D 5+ & 780 - 1070nm O.D7+ | 740 - 1100nm DIR LB5 & 800 - 1070nm IR LB7 |
| DTY | 980&1064&1320nm | 40% | 800 - 1700nm O.D 4+ & 900 - 1100nm O.D 5+ | 800 - 1400nm DIR LB4 & 1400 - 1700nm DI LB3 |
| YHP | High Power 808&980&1064nm | 60% | 800 - 1100nm O.D 5+ & 1060 - 1070nm O.D 7+ | 800 - 1100nm DIR LB5 & 1000 - 1070nm IR LB7 |
| CHP | 10600nm | 90% | 9000-11000nm O.D 6+ | 9000-11000nm DI LB3 |
|
|
|
| IPL | 200 – 1400nm | 10% | IPL Machine | |
|
|
|
| YLW | 1064nm Laser Window | 40% | 800 -1100nm O.D 4+ & 1064nm O.D 6+ | 1064nm DIR LB5 |
Quality Control:
Our QC department is composed of 3 QC engineers and 5 QC
assistants,with the expanding of our output,more QC staffs are
needed. We strictly conduct international quality standards to meet
the clients demands.
CE Certificate:
We usually attend the exhibition @UAE-Dubai Derma, ITALY-Cosmoprof Worldwide Bologna,
GERMANY-Beauty Duesseldorf, SPAIN-Cosmo Beauty, CHINA-Laser
Photonics, etc.
If you would like to visit our booth, welcome book an appointment
advance. :)
FAQ :
1. Are you a manufactuer or trading company?
We are a manufactuer specialized in laser safety field over 10
years.
2. How is your product quality?
We have the guarantee from the material,even every procedure.
3. Can you make sure all of the products consistent?
Yes,we have passed the ISO9000 certification,CE all products will
be as good as the samples.
4. How to proceed an order for glasses ?
Firstly let us know your requirements or application;
Secondly we quote according to your requirements or our
suggestions;
Thirdly customer confirms the samples and laces deposit for formal
order;
Fourthly we arrange the production.
5. How can I trust you ?
(1) Professional & experience manufacturer;
(2)Have cooperated with many famous brand;
(3)Quality is our priority as we concern about what our customer
purchase from us;
(4)Good after-sells services.
